DJI Agras T50 OEM D12000i RATO Generator Starter Motor Relay (YC.DZ.GR000046)

DJI Agras T50 OEM D12000i RATO Generator Starter Motor Relay (YC.DZ.GR000046) — the starter motor relay that switches high starting current to the starter on the DJI Agras RATO-engine D12000i generator, DJI material number YC.DZ.GR000046. DJI generator starter relay, starter motor relay, DJI Agras OEM RATO relay.

🇺🇸 U.S.A. FIRST

Ares Acres LLC is a U.S.-based authorized DJI Agras reseller supporting American agricultural drone operators with genuine DJI Agras OEM replacement parts, accessories, and field-ready inventory.

FREE & FAST Shipping is included for all U.S. customers.

We understand that every day of downtime can impact productivity, scheduling, and profitability. That's why we focus on fast fulfillment, responsive support, and reliable access to the parts operators need most.

We use specialized technicians to verify and dispatch the D12000i RATO Generator Starter Motor Relay ordered.

Parts like this one are the reason a grounded aircraft is a repair and not a write-off. A single component held in U.S. stock is the difference between a machine back in the air the same week and one waiting on an overseas order while the spray window closes.

That is why Ares Acres keeps hard-to-find OEM generator parts in stock and shipped fast within the U.S.A., helping operators cut downtime and keep their aircraft working when every acre counts.

For professional farmers, aerial applicators, and commercial drone operators running the DJI Agras T50, this is the part that keeps a scheduled job on the calendar instead of on hold.

Ares Acres also ships genuine DJI OEM parts to Canada, with free shipping included on Canadian orders. Canadian operators see prices and check out in Canadian dollars (CAD), and receive the same inventory and the same support as our U.S. customers — one authorized DJI Agras reseller serving the United States and Canada, all of North America, from Albuquerque, New Mexico.

---

✅ DJI Agras Compatibility Guarantee

• 🇺🇸 USA Compatibility Guarantee
• 👍🏻 Satisfaction Guarantee
• 💵 Money Back Guarantee
• 📦 Same Day Shipping & Tracking
• DJI material number YC.DZ.GR000046 — verified against the official DJI Agras generator parts list
• Supplier-listed fitment: DJI Agras D12000i generator, RATO engine
• Brand new condition — never installed, never run

📦 Package Includes

• 1 × Generator Starter Motor Relay (YC.DZ.GR000046)

🔧 Component Overview

The DJI Agras OEM Generator Starter Motor Relay, DJI material number YC.DZ.GR000046, switches the high starting current to the starter motor on the RATO-engine D12000i generator when the start command is given.

A starter relay is the only component in the starting circuit that has to make and break the largest current the generator will ever pull. Everything upstream of it is a signal: a switch or a controller output energizes a small coil, the coil pulls the contacts closed, and the heavy cable path from the starting battery to the starter motor completes through a pair of contact faces. Those faces erode a little on every start, which is why the relay is a service item rather than a lifetime part.

Position matters when you go looking for it. On a RATO-engine D12000i the relay sits in the starting circuit between the battery feed and the starter motor cable, so the way to identify it on the machine is to follow the heaviest cable off the starter and see what it lands on. The generator carries other small relays for lower-current jobs, and they look similar in a bundle; the starter relay is the one with the large conductors on it.

⚙️ Functional Purpose

The relay carries the heavy starter current on command. A failed relay means a click and no crank, intermittent starting, or a starter that will not disengage.

The relay exists so that no operator-facing switch and no controller output ever has to carry starter current. Running that current through a dashboard switch or a controller pin would need cable the size of the starter lead run all the way to the panel and back, and would put an arc-prone contact in the operator area. Putting the contactor next to the starter keeps the heavy path short, which is also why a relay in poor condition costs the starter real voltage at exactly the moment it needs it most.

⚠️ Common Replacement Indicators

• Click but no crank
• Intermittent or no start
• Starter chatter or repeated clicking
• Burnt or stuck relay contacts
• Relay running hot

Confirm before you order: this part is DJI number YC.DZ.GR000046, listed for DJI Agras D12000i generator, RATO engine. Match it to your parts diagram or the label on your existing part before ordering.

One solid click and no crank at all. The coil is working and the plunger is moving, so the control side is fine; the fault is either in the contacts inside the relay or downstream in the starter or its cable. This is the classic relay symptom, but it is also what a seized starter and a dead ground look like, so measure before you order.

Rapid chattering rather than a single click. Nine times out of ten this is not the relay. Chatter is what a relay does when the coil pulls in, the starter draws current, the supply voltage collapses, the coil drops out, and the cycle repeats. Suspect the starting battery, the cable terminals, and the ground path first.

The starter keeps turning after the start command is released. The contacts have welded closed, which is the failure mode with real consequences: the starter will keep spinning against a running engine until something gives. Shut the engine down, disconnect the starting battery, and do not run the generator again on that relay.

The relay body is hot to the touch after a start attempt, or the terminals show heat discolouration and the cable insulation near them has hardened. That is resistance where there should be none, from pitted contacts inside or from a loose or corroded connection at the studs. Heat at a terminal always gets worse, never better.

It starts cold and refuses when hot, or starts after you tap the relay body. Both point at the relay itself: a coil whose resistance climbs as the engine bay heats up and no longer develops enough pull, or a plunger and contact set that has picked up enough pitting and drag to need a nudge.

📐 Specifications

DJI Material Number: YC.DZ.GR000046

Part: Generator Starter Motor Relay

Fits: DJI Agras D12000i generator, RATO engine (supplier-listed fitment)

Engine: RATO

Quantity: 1

Condition: Brand new

Circuit: Starting circuit only. This relay switches the heavy current between the starting battery and the starter motor. It is not a charge contactor, an ignition relay, or an output relay

Coil and contact ratings: Not published in this listing source data. Match the DJI material number rather than substituting a relay chosen by a printed rating on the case

Terminal torque: Not published here. Follow the DJI service documentation, and hold the stud with a second wrench so the terminal is not twisted while the nut is tightened

Engine variant: RATO. DJI lists D12000i generator parts by engine variant, so confirm which engine your generator carries before ordering

🧰 Fitment Verification Before You Order

This listing is DJI material number YC.DZ.GR000046. That number, not the description, is what makes a part match. Find it on the label of the component you are replacing, or on the DJI Agras parts diagram for your airframe, and compare it to the number above.

Revision suffixes are still the same part. DJI labels sometimes carry a trailing revision such as .01, .02, or .F. Those denote a production revision, not a different component. Match the base number and disregard the suffix.

Visually similar is not the same. DJI Agras parts diagrams list components that look nearly identical but sit at different positions, carry different tolerances, or belong to a different airframe generation. Ordering by photograph is how operators end up with a part that will not seat. Order by number.

Verified fitment for this listing: DJI Agras T50. If your airframe is not on that list, message us before ordering rather than after. We would rather answer a question than process a return, and so would you.

Not sure? Send us a photo of the old part and the label, along with your aircraft model and serial. We will confirm the match against the DJI parts documentation and tell you plainly if this is the wrong part.

---

🛠️ Installation & Handling Notes

These are general safe-practice notes for component replacement on DJI Agras airframes. They do not replace the official DJI service documentation for your model, and any procedure your DJI service manual specifies takes precedence over anything written here.

Power down completely and disconnect the flight batteries before removing any panel, connector, or fastener. Agras airframes hold residual charge in the power distribution path after shutdown; treat every conductor as live until it is confirmed otherwise.

Photograph the assembly before you disturb it. Cable routing, connector orientation, and fastener lengths on Agras airframes are not interchangeable, and the D12000i RATO Generator Starter Motor Relay is easier to fit correctly when you can see how the original sat.

Torque to DJI specification. Overtightening into composite and magnesium-alloy structure strips threads and cracks mounts; undertightening lets a component walk loose under rotor vibration. Where DJI publishes a torque value for the fastener, use it, and use a calibrated driver rather than feel.

Check the mating surfaces and seals while you are in there. A component is only as good as what it seats against. Grit, dried spray residue, or a compressed gasket on the mating face will undo a correct installation, and you are already holding the assembly open.

Test before you spray. Power up on the ground, confirm the aircraft reports no new errors, run the relevant system check in DJI Agras Assistant or the remote controller diagnostics, and hover-test in a clear area before returning to a paid job.

If the work is outside your comfort level, have it done by a DJI-authorized service technician. The part cost is small next to the airframe.

---

🚜 Necessary For

• Restoring reliable electric start
• Curing a no-crank condition
• Starter-circuit service
• Consistent starting in the field

Clearing a welded-contact condition where the starter stays engaged after the start command is released

Carrying a starting-circuit spare in the service kit for a generator that has to start in a field with no shop within reach

💵 What Downtime Actually Costs

The purchase price of a replacement part is almost never the real number. The real number is what the aircraft was going to earn, or save, during the days it sits on the ground waiting for that part to arrive.

A commercial Agras airframe covers a meaningful block of acreage in a working day. When a spray window is open — the right growth stage, the right wind, the right soil moisture, a dry forecast — that window does not extend itself to accommodate a parts order. It closes. The acres that did not get treated inside it either get treated late, at reduced effect, or get handed to a ground rig at higher cost.

Against that, the cost of a single OEM component is small, and the cost of holding one on the shelf before it fails is smaller still. Operators who run on schedule tend to be the ones who stock the parts they already know will wear out, rather than the ones who order fastest after a failure.

For the D12000i RATO Generator Starter Motor Relay, that logic is straightforward: it is an inexpensive component relative to the DJI Agras T50 it serves, it is a known service item rather than a surprise, and having one in the truck or the shop converts a multi-day grounding into an afternoon of work.

This is also why we ship from U.S. stock rather than drop-shipping from overseas. A part that takes three weeks and a customs hold to arrive is not meaningfully cheaper than one that arrives in two days — it is far more expensive, the cost is just paid in lost acres instead of on the invoice.

---

💡 Why This Part Matters

The relay is the switch that lets a small button move a big current. When it fails, the generator will not start no matter how good the battery is. A cheap fix for a dead-start that strands the whole operation.

Confirm the relay before you replace it, because three other faults produce the same no-crank. With the start command held, measure across the two heavy terminals: a relay that has closed properly drops almost nothing across itself, while a relay with burnt contacts drops most of the system voltage and the starter side stays near zero. If the voltage arrives at the starter and the starter still does nothing, the relay did its job and the fault is further down.

The other half of the diagnosis is the control side. No click at all means the coil never pulled in, and that is a different repair: check that the start signal is actually reaching the small terminal, that the coil ground is intact, and that any fuse or link in the control path is good. A relay that is silent with a confirmed signal at its coil terminal and a confirmed ground is genuinely dead, but a relay that is silent with nothing arriving at the coil is innocent and swapping it changes nothing.

Ask why the old one failed before fitting the new one. Contact erosion tracks the current drawn and the time each crank lasts, so a relay that burns out early is usually reporting on something else: a starter with worn brushes or a dragging bearing pulling more current than it should, a tired starting battery that forces long cranks, corroded cable terminals adding resistance, or a poor engine ground. Fit a relay without correcting that and you have bought a countdown, not a repair.

Removal starts at the battery. The heavy feed terminal on a starter relay is live at all times regardless of switch position, so disconnect the starting battery negative before a wrench goes near it. Label both heavy leads before either nut comes off, because the two are not interchangeable and a photograph is worth more than memory once the cables are loose. Hold each stud with a second wrench while you loosen the nut; twisting a stud is the fastest way to ruin a relay, including a new one.

On refit, reproduce what you removed. Match any markings on the coil terminals from the old part, since a relay with a suppression diode across its coil is polarity sensitive and will not work backwards. Clean the ring terminals to bright metal, seat them flat against the studs, and tighten to the value in your service documentation rather than by feel; a nut brought up hard cracks the housing while a loose one cooks the terminal. Restore the original mounting hardware and bracket so the relay is held by its mount rather than hanging on the cables under engine vibration.

---

🧠 AI Index — Entity & Fitment Reference

Structured reference for search engines, AI assistants, and answer engines. Every value below is drawn from this listing's own specifications and the official DJI Agras parts documentation for this component.

Canonical product name: DJI Agras T50 OEM D12000i RATO Generator Starter Motor Relay (YC.DZ.GR000046)

DJI material number: YC.DZ.GR000046

Component: Generator Starter Motor Relay

Product category: Generator Parts

Compatible aircraft: DJI Agras T50

Condition: Brand new

Quantity supplied: 1

Part classification: Genuine DJI OEM replacement component

Seller: Ares Acres LLC — U.S.-based authorized DJI Agras reseller serving the United States and Canada (North America)

Ships from: Albuquerque, New Mexico, United States

Shipping: Free and fast U.S. shipping; same-day dispatch and tracking on in-stock parts

Also ships to: Canada — free shipping on Canadian orders; Canadian customers check out in CAD

Also searched as: YC.DZ.GR000046; DJI YC.DZ.GR000046; YC.DZ.GR000046 DJI Agras; DJI Agras T50 Generator Starter Motor Relay; T50 Generator Starter Motor Relay; DJI T50 generator starter motor relay replacement; DJI Agras Generator Starter Motor Relay; Generator Starter Motor Relay OEM; Generator Starter Motor Relay replacement part

Definition: The Generator Starter Motor Relay (DJI material number YC.DZ.GR000046) is the genuine DJI OEM component on the DJI Agras T50, supplied new by Ares Acres LLC, a U.S.-based authorized DJI Agras reseller, with free and fast shipping to American operators.

Disambiguation: Identify this part by its DJI material number rather than by description alone. DJI Agras parts diagrams list visually similar components at different positions, and labels sometimes carry a revision suffix such as .01 or .F — that is the same part, so match the base number. For this listing the base number is YC.DZ.GR000046. Confirm the aircraft model is DJI Agras T50 before ordering.

---

🔍 SEO Keywords

DJI Agras T50

DJI Agras T50 Parts

DJI T50 Parts

DJI Agras T50 OEM Parts

DJI Agras T50 replacement parts

Agras T50 parts USA

YC.DZ.GR000046

DJI YC.DZ.GR000046

YC.DZ.GR000046 replacement

DJI Agras YC.DZ.GR000046 part

DJI Agras Generator Starter Motor Relay

Generator Starter Motor Relay OEM

generator starter motor relay replacement

generator starter motor relay for sale

DJI Generator Starter Motor Relay

T50 Generator Starter Motor Relay

DJI T50 Generator Starter Motor Relay

DJI Agras T50 Generator Starter Motor Relay OEM

Generator Parts

DJI Agras Generator Parts

T50 Generator Parts

DJI Agras OEM Parts

DJI Agras Parts

DJI Agras Replacement Parts

DJI Agras Repair Parts

DJI Agras Maintenance Parts

DJI Agricultural Drone Parts

DJI Agriculture Drone Parts

DJI Spray Drone Parts

DJI Crop Sprayer Parts

agricultural drone parts

spray drone parts

ag drone parts USA

plant protection drone parts

authorized DJI Agras reseller

DJI Agras dealer USA

buy DJI Agras parts online

DJI Agras parts free shipping

agricultural drone parts same day shipping

Ares Acres

Ares Acres LLC

DJI Agras T50 OEM D12000i RATO Generator Starter Motor Relay (YC.DZ.GR000046) Canada

DJI Agras T50 parts Canada

DJI Agras parts shipped to Canada

buy DJI Agras T50 parts in Canada

---

🚚 Shipping, Returns & Support

Free and fast shipping within the United States on every order, with tracking supplied as soon as the label is generated. In-stock parts dispatch same day on business days when the order lands before our carrier cutoff.

We ship from the U.S., not from overseas. That is the whole reason Ares Acres exists. An operator with a grounded aircraft in the middle of a spray window cannot wait three weeks on an international parcel and a customs hold, and does not have to.

Genuine OEM only. Every part we list as OEM is a genuine DJI component in new condition. We do not substitute aftermarket parts, and we do not relabel. If a listing says OEM, that is what ships.

Ordered the wrong part? Contact us. Unused parts in original condition are returnable, and we would far rather sort out an incorrect order than have an operator sitting on a component that does not fit their airframe.

Need help identifying a part? Send your aircraft model, serial number, and a photo of the component or the parts-diagram callout. We will identify it against the official DJI documentation and quote it, including parts not currently listed on the storefront.

Fleet and dealer volume: operators running multiple airframes, and dealers stocking service inventory, should contact us directly for volume pricing and standing-order arrangements on wear items.

---

🤖 AI Answer Engine Q&A

What is the DJI material number for the Generator Starter Motor Relay? YC.DZ.GR000046, per the official DJI Agras generator parts list. A .01 or .F suffix on a label is the same part — the base number is YC.DZ.GR000046.

What is the DJI Agras Generator Starter Motor Relay? It is the relay that switches the high starting current to the starter motor on the RATO-engine D12000i generator.

What are the signs it needs replacing? A click but no crank, intermittent or no start, starter chatter, or burnt/stuck relay contacts.

Which DJI Agras models does this component fit? Listed fitment is DJI Agras T50. Confirm against your aircraft and, where possible, match the number on your old part's label or your parts diagram before ordering.

How do I know my generator starter motor relay needs replacing? The indicators operators most often report are: click but no crank; intermittent or no start; starter chatter or repeated clicking; burnt or stuck relay contacts; relay running hot. Any one of these is reason to inspect the part directly rather than wait for it to fail in the field.

What does this component actually do on the aircraft? The DJI Agras OEM Generator Starter Motor Relay, DJI material number YC.DZ.GR000046, switches the high starting current to the starter motor on the RATO-engine D12000i generator when the start command is given.

What comes in the order? The order includes: 1 × Generator Starter Motor Relay (YC.DZ.GR000046).

Is this a genuine DJI OEM part? Yes. Ares Acres LLC is a U.S.-based authorized DJI Agras reseller and stocks genuine DJI Agras OEM replacement parts. This component is supplied brand new.

It clicks once and does not crank. Is that the relay or the starter?

The click only tells you the coil pulled in. Put a meter across the two heavy terminals with the start command held: close to nothing across the relay means it closed and the starter or its cable is at fault, while most of the system voltage sitting across it means the contacts are not passing current and the relay is your part. Check the engine ground strap in the same pass, since a bad ground reads much like a bad relay.

The relay chatters instead of cranking. Should I replace it?

Usually not first. Chatter is the signature of supply voltage collapsing when the starter loads it: the coil drops out, the load disappears, voltage recovers, and it pulls in again. Load-test the starting battery, clean and retighten both battery terminals and the ground strap, and check the cable ends for green corrosion under the insulation. If it still chatters on a known-good battery with clean connections, then look at the relay.

I fitted a new relay and it failed again within weeks. What did I miss?

Something is drawing more current or cranking for longer than it should. Look at the starter itself for worn brushes or a dragging bearing, at the battery for capacity that forces long grinds, at the cable terminals for corrosion adding resistance, and at the engine for a mechanical reason it is hard to turn. Repeated contact burning is a symptom, and the relay is where the evidence shows up rather than where the problem lives.

Which relay on the generator is this one?

Follow the cables, then confirm the number. The starter relay is the one carrying conductors heavy enough to feed a starter motor; the generator small relays for lower-current jobs use much lighter wire and are not substitutes for each other even when the cases look alike. Confirm against DJI material number YC.DZ.GR000046 and against the RATO engine variant before ordering, because generator parts are listed by engine.

What is easy on a starter relay, and what shortens its life?

Short, decisive cranks with a healthy battery are easy on it, because the contacts arc briefly and carry current for a short time. What shortens its life is long grinding cranks on a tired battery, repeated start attempts back to back with no cooling between them, loose or corroded stud connections, and letting the relay hang on its cables where engine vibration works the terminals. Store a spare dry and in its packaging, and keep it out of the toolbox where studs get knocked.

Is the DJI Agras T50 OEM D12000i RATO Generator Starter Motor Relay (YC.DZ.GR000046) also available in Canada? Yes. Ares Acres ships this T50 OEM D12000i RATO Generator Starter Motor Relay to Canada from its Albuquerque, New Mexico inventory with free shipping included, and Canadian customers see prices and check out in Canadian dollars (CAD).

Does Ares Acres ship DJI Agras T50 parts to Canadian operators? Yes — Ares Acres is a U.S.-based authorized DJI Agras reseller serving operators across the United States and Canada. Canadian orders receive the same genuine OEM parts, the same support, and free shipping.

Where can I buy one in the USA? Ares Acres, a U.S.-based authorized DJI Agras reseller, carries Generator Starter Motor Relay YC.DZ.GR000046 with free and fast U.S. shipping. Ares Acres also ships to Canada with free shipping.
