DJI T100 Dual-Battery Spraying: Preflight y Guía de Seguridad
El DJI T100 Dual-Battery Spraying System (LS100-DB) cambia dos variables importantes frente a una configuración estándar: el aircraft opera con dos Intelligent Flight Batteries y el spraying payload publicado por DJI es 90 kg. Eso exige un preflight que revise no solo spray hardware, sino también battery pairing, firmware support, cable security, takeoff-weight recommendation y el estado de protección IPX6 del módulo.
Respuesta rápida: confirme que el aircraft sea un DJI Agras T100 con firmware que soporte LS100-DB; use dos batteries idénticas cuando opere dual-battery spraying; revise cables y mechanical hardware; no exceda el payload recomendado por DJI Agras; verifique seals/waterproof covers; y no desarme factory-installed components. DJI publica 100 L de tank volume, 90 kg de operating payload y aproximadamente 50% más hover time al mismo payload frente a la configuración comparada por DJI.
1. LS100-DB es exclusivo del T100
DJI especifica que el dual-power spraying system es compatible únicamente con el T100 aircraft. No debe instalarse en otros modelos ni utilizarse fuera de agricultural plant-protection applications.
2. Firmware support es obligatorio
El aircraft firmware debe soportar el dual-battery spraying system. Antes del primer uso, confirme que el T100 y el DJI Agras app reconocen correctamente el payload configuration.
3. Dual battery significa batteries idénticas
DJI indica que, para T100 dual-battery spraying o lifting, ambas batteries deben ser idénticas. No mezcle battery families o packs de diferente model designation en la misma dual-battery configuration.
4. DB2160 y DB2212 pueden aparecer en el ecosistema T100
DJI señala que DB2160 y DB2212 Intelligent Flight Batteries están disponibles según market. La regla para dual-battery operation sigue siendo que ambas batteries sean del mismo tipo.
5. Battery pairing debe revisarse antes de cada mission
- same battery model;
- both packs physically undamaged;
- connectors clean;
- no unresolved battery warning;
- both packs properly seated;
- no abnormal voltage/capacity mismatch warning in DJI Agras.
6. Tank volume: 100 L
DJI publica un 100 L spray tank para el LS100-DB.
7. Operating payload: 90 kg
El dual-battery spraying configuration publica 90 kg operating payload. Esto no debe confundirse con el 100 kg spraying payload de la standard single-battery spray system.
8. The app recommendation overrides a blind maximum-load assumption
DJI establece que el max spray-tank load depende del aircraft takeoff weight. DJI Agras recomienda un payload según current aircraft state y surroundings. Do not overload.
9. 90 kg es una specification, no un target universal
Elevation, temperature, battery condition y actual aircraft status pueden hacer que la app recomiende un payload menor.
10. Published endurance advantage
DJI states that, at the same payload, the dual-battery spraying configuration can increase hover time by approximately 50%. Treat that as manufacturer performance guidance rather than a guaranteed mission-duration figure.
11. Longer endurance changes field planning
Más endurance puede reducir battery swaps, pero también significa que cada sortie puede carry spray material for longer. Route length, chemical volume, refill location y battery reserve deben planificarse juntos.
12. Cable connections must be correct and secure
DJI specifically warns to make sure connections are correct and firmly seated. Loose or partially engaged connectors are not acceptable in a dual-battery/high-current configuration.
13. Inspect cables for damage
Look for pinching, abrasion, bent connectors, contamination or routing that could contact moving or sharp parts.
14. Mechanical parts can injure hands
DJI warns about sharp or moving mechanical components. Perform hands-on checks with the aircraft powered down and secured.
15. Do not disassemble factory-installed parts
Removing components that were mounted before shipment can reduce ingress-protection performance and can create an unsupported configuration.
16. Protection rating: IPX6 under stable laboratory conditions
The LS100-DB product information lists IPX6 under stable laboratory conditions.
17. IPX6 protection is not permanent
Age and wear can reduce protection over time.
18. Collision can compromise sealing
If a collision deforms a seal structure, do not assume the original ingress protection remains intact.
19. Cracked or damaged housing seals matter
Any damaged sealing surface should move the system into inspection/service rather than normal spraying.
20. Waterproof covers must be fully secured
A loose protective cover can reduce the published ingress-protection performance.
21. Water damage is not covered by the product warranty
DJI states that liquid-damage coverage should not be assumed simply because the device has an IPX6 laboratory rating.
22. Preflight battery check
- verify both batteries are identical models;
- inspect shells, handles and connectors;
- confirm no swelling, leakage or impact damage;
- install both packs fully;
- power on and review DJI Agras status;
- stop if a voltage/capacity mismatch or battery error appears.
23. Preflight spraying-system check
- confirm LS100-DB is correctly installed;
- check tank and structural mounting;
- inspect spray hoses and connectors;
- confirm nozzle/sprinkler configuration;
- check for leakage;
- confirm flow-meter/spraying-system status in DJI Agras;
- verify tank cover and all protection covers.
24. Preflight firmware and app check
Confirm the aircraft recognizes the dual-battery payload and there are no unsupported-device, firmware or payload-system errors.
25. Preflight takeoff-weight check
Review the payload recommendation in DJI Agras before filling to the maximum nominal tank value. Do not use a previous mission's payload number as a substitute for the current recommendation.
26. Battery SOC should be operationally balanced
If DJI Agras reports a meaningful battery voltage or capacity difference, do not take off until the packs are brought back into an acceptable matched state.
27. Route planning matters more with longer endurance
Longer endurance can support larger field segments, but route planning should still preserve safe return/landing reserve rather than using every extra minute of hover capability.
28. Spraying payload and battery endurance are linked
More payload increases aircraft demand. Plan the actual mission around the app recommendation, environment and intended spray rate.
29. Use a consistent battery pair for repeatable operations
Fleet teams may benefit from labeling dual-battery pairs so operators do not accidentally mix battery models or unknown-history packs.
30. Record the pair used on each sortie
- battery ID A;
- battery ID B;
- battery model;
- starting charge;
- warning status;
- payload recommendation;
- actual loaded payload;
- mission outcome.
31. After landing, inspect both batteries
Do not inspect only the battery that appears warmer or shows lower charge. Both packs are part of the same propulsion-energy system.
32. Cooling remains part of the operating loop
Move used packs into the correct battery-cooling/charging workflow before the next rotation.
33. Do not use a damaged pair just to preserve matching
If one pack is damaged or unsafe, remove it from service. “Matching” does not justify keeping a suspect battery in rotation.
34. If one battery generates a warning
Record which battery generated the warning and test only through supported diagnostic procedures. Avoid repeatedly swapping it back into flight without understanding the cause.
35. If the dual-battery payload is not recognized
Check firmware support, physical connections and payload-system installation before concluding the aircraft or spray system needs replacement.
36. If the app recommends less than 90 kg
Use the lower recommendation. The source explicitly says the app recommendation depends on current aircraft status and surroundings.
37. If seals were damaged in a collision
Do not rely on the original IPX6 rating until the affected structure has been inspected and restored.
38. If a waterproof cover will not secure correctly
Treat it as a service finding rather than operating as normal in wet conditions.
39. Dual-battery spraying SOP
- confirm T100 + supported firmware;
- confirm LS100-DB installed;
- use identical batteries;
- inspect both packs/connectors;
- review DJI Agras for mismatch/warnings;
- inspect cables/mechanical hardware;
- verify seals and covers;
- review app payload recommendation;
- load within recommendation;
- complete normal T100 preflight;
- record battery pair and payload;
- post-flight inspect and cool both packs.
40. Common error: mixing battery types
DJI specifically says both batteries should be identical for T100 dual-battery spraying/lifting.
41. Common error: treating 90 kg as mandatory payload
It is the published operating payload, not a command to load 90 kg under every condition.
42. Common error: ignoring firmware support
The LS100-DB requires compatible aircraft firmware.
43. Common error: assuming IPX6 is permanent
It is not; aging, wear, collisions and loose covers can reduce protection.
44. Frequently asked questions
What is the T100 dual-battery spraying system model?
LS100-DB.
What is the spray tank volume?
100 L.
What is the published operating payload?
90 kg.
Can I mix DB2160 and DB2212 in one dual-battery setup?
DJI says both batteries must be identical for dual-battery spraying/lifting.
Does dual battery increase endurance?
DJI reports approximately 50% more hover time at the same payload in its published comparison.
Is IPX6 permanent?
No.
Source and revision
Primary sources: DJI T100 Dual-Battery Spraying System Product Information v1.0 (2026-06-22) and the current DJI AGRAS T100 specifications/product page.
